3D Exercise 149

Exercise 149

Features used to make this exercise:

In this CAD tutorial we'll use the features:

1. Sweep: Creates a 3D shape by moving a profile along a path.

2. Extrude: Extends a 2D sketch into a 3D shape by adding or removing material.

3. Rectangular Pattern: Duplicates features or bodies in a grid of rows and columns.

All dimensions are in mm/g/s/ISO

#Fusion360 #Solidworks #Inventor #Autocad #FreeCAD

2D Sketch

2D Sketch - Exercise 149

Tip: Subscribe to the channel for more tutorials like this.

Tutorial In Autodesk Fusion: https://youtu.be/iJb6AKK7PqE
