3D Exercise 162

Exercise 162

Features used to make this exercise:

In this CAD tutorial we'll use the features:

1. Extrude: Pushes or pulls a flat 2D sketch in a straight line to add or remove material.

2. Cylinder: Quickly generates a solid 3D cylindrical shape directly, without needing a separate 2D sketch.

3. Hole: Creates precise, standard engineering holes (like tapped or clearance holes) directly into a solid part.

4. Fillet: Rounds off sharp edges to create a smooth, curved transition.




All dimensions are in mm/g/s/ISO

#Fusion360 #Solidworks #Inventor #Autocad #FreeCAD

2D Sketch

Sketch 162

Tip: Subscribe to the channel for more tutorials like this.

Tutorial In Autodesk Fusion: https://youtu.be/HVUTnB7F3fQ

Tutorial in FreeCAD:
