3D Exercise 31
- Breno Cruz
- há 5 dias
- 1 min de leitura
In this CAD tutorial we'll use the features:
🧱 Extrude
Extrude is the most fundamental command for turning a 2D sketch into a 3D solid. It works by extending a sketch profile in a straight line, either to add material (a "join" operation) or to remove material (a "cut" operation).
📐 Rib
The Rib command is used to create a thin-walled support feature that adds strength and rigidity to a part. You create a rib by sketching a single line (or multiple lines) that represents the path of the rib, and the command automatically creates the feature with a specified thickness, typically perpendicular to the sketch plane. Ribs are essential for reinforcing walls and preventing them from bending under load.
🔄 Mirror
The Mirror command is used to create a symmetrical copy of a feature, body, or component. It's a powerful tool for designing symmetrical parts, as you can model one half and then mirror it to create the other. You select the object to be copied and the plane or face to mirror it across.
All dimensions are in mm/g/s/ISO
3D Sketch
Exercise 31 - 3D practice drawing for all CAD software ( AutoCAD, SolidWorks, 3DS Max, Autodesk Inventor, Fusion 360, CATIA, Creo Parametric, SolidEdge etc.)
Tip: Subscribe to the channel for more tutorials like this.
Tutorial In Autodesk Fusion: https://youtu.be/3iVP_RaXZAY
