In this CAD tutorial we'll use the features:
1. Plane Along Path (Construction)
Definition: Creates a sketch plane that is perpendicular to a selected line or curve (path). How it works: You select a path (like a 3D sketch line) and drag the plane to a specific point (e.g., the very end). Best for: Setting up the starting point for a complex sweep or positioning a feature (like a nozzle) somewhere along a tube.
2. Extrude
Definition: The standard tool for creating 3D geometry from a sketch. How it works: You select a profile and give it thickness. Best for: Creating brackets, flanges, or mounting plates that will attach to your tubing.
3. Pipe
Definition: A "shortcut" tool that creates a tube or rod along a path. How it works: This is faster than "Sweep." You don't need to draw a circle profile. You simply select a line (path), choose the section shape (Circle, Square, or Triangle), and set the size. Best for: Roll cages, furniture frames, cooling lines, or handlebars.
4. Mirror
Definition: Creates a symmetrical copy of a body or feature. How it works: You model the left half of your object, select a mirror plane (like the center plane), and Fusion generates the right half. Best for: Ensuring symmetry. Note: Often, when you mirror a "Body," you end up with two separate halves that touch but aren't one piece yet.
5. Combine
Definition: Performs Boolean operations (Join, Cut, Intersect) between solid bodies. How it works:
Join: Glues two separate bodies together into one single solid (e.g., merging your Mirrored halves).
Cut: Uses one body to remove material from another (like a cookie cutter).
Intersect: Keeps only the volume where two bodies overlap. Best for: Merging a mirrored left/right side into a single part, or cutting a complex shape out of a block.
6. Shell
Definition: Hollows out a solid body. How it works: You select a face to remove (like the end of a cylinder) and set a wall thickness. Best for: If you created a solid rod using the "Pipe" tool (without the hollow option), you can use Shell to turn it into a hollow tube with open ends.
7. Fillet
Definition: Rounds off sharp edges. How it works: Applies a radius to edges. Best for:
Weld Simulation: Adding a fillet where a tube meets a plate can look like a weld bead.
Smoothness: Rounding the corners of your extruded brackets.
All dimensions are in mm/g/s/ISO
3D Sketch
Exercise 62 - 3D practice drawing for all CAD software ( AutoCAD, SolidWorks, 3DS Max, Autodesk Inventor, Fusion 360, CATIA, Creo Parametric, SolidEdge etc.)
Tip: Subscribe to the channel for more tutorials like this.
Tutorial In Autodesk Fusion: https://youtu.be/fXlmjp8McOM
